HOBO Stainless Temperature (4900 ft.) Data Logger U12-015
Jika anda tertarik untuk membeli alat HOBO Stainless Temperature (4900 ft.) Data Logger U12-015 yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :
PT. Samudra Teknik Solusindo
Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Deskripsi
HOBO Stainless Temperature (4900 ft.) Data Logger U12-015 ideal untuk makanan, farmasi, autoklaf, dan aplikasi lain yang memerlukan data suhu dengan akurasi tinggi. Dengan rentang suhu yang luas (-40 hingga 125C) dan housing baja tahan karat kelas makanan, pencatat data ini tahan terhadap kondisi proses, mulai dari pasteurisasi hingga pembekuan kilat dan pencucian. Logger ini juga sangat cocok untuk aplikasi di bawah air bersuhu tinggi atau dalam.
Features
- Food-grade 316 Series Stainless Steel
- High-accuracy, extended temperature range
- Suitable for high pressure applications to 2200psi
- Fast readout via direct USB interface
- Compatible with HOBOware and HOBOware Pro for logger setup and graphing & analysis
Spesifikasi
| Parameter | Specification |
|---|---|
| Measurement Range | -40° to 125°C (-40° to 257°F) |
| Accuracy | ±0.25°C from 0° to 50°C±0.45°F from 32° to 122°F (see manual for plot) |
| Resolution | 0.03°C at 25°C0.05°F at 77°F (see manual for plot) |
| Drift | 0.09°F/year + 0.2°F/1000 hrs above 212°F |
| Response Time in Air (1 m/s airflow) | U12-015: <10 minutes, typical to 90%U12-015-02: 2.25 minutes, typical to 90% |
| Response Time in Water | U12-015: <3.5 minutes, typical to 90%U12-015-02: 20 seconds, typical to 90% |
| Time Accuracy | ±2 minutes per month at 25°C (77°F) |
| Operating Environment | Air, water, steam, 0 to 100% RH |
| Operating Temperature | Logging: -40° to 125°C (-40° to 257°F)Launch/readout: 0° to 50°C (32° to 122°F), per USB spec |
| Battery Life | 3 years typical use, factory replaceable |
| Memory | 64K bytes (43,000 12-bit measurements) |
| Construction | 316 series stainless steel, EPDM or Viton O-ring; see Food-Grade Compliance section for details |
| Weight | U12-015: 72 g (2.5 oz)U12-015-02: 82 g (2.9 oz) |
| Logger Dimensions | 17.5 × 101.6 mm (0.69 × 4.00 inches) |
| Probe Dimensions | U12-015-02 only: 4 × 124 mm (0.16 × 4.90 inches) |
| Pressure/Depth Rating | 2200 psi max1500 m / 4900 ft max |
| NIST Certificate | -22°F to 248°F |
