HOBOnet Rainfall (inches) Sensor RXW-RGE-xxx
Jika anda tertarik untuk membeli alat HOBOnet Rainfall (inches) Sensor RXW-RGE-xxx yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :
PT. Samudra Teknik Solusindo
Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Deskripsi
Mencatat curah hujan dengan kenaikan 0,2 milimeter. Sensor nirkabel HOBOnet mengkomunikasikan data secara langsung ke HOBO RX3000 atau stasiun HOBO MicroRX atau meneruskan data melalui sensor nirkabel lainnya kembali ke stasiun pusat. Sensor-sensor ini telah dikonfigurasikan sebelumnya dan siap digunakan, dan data diakses melalui HOBOlink, platform perangkat lunak cloud Onset yang inovatif.
Features
Sensor Features
- Resolution of 0.2 millimeters
- Bird spikes
- Debris screen that locks in place
- Designed to meet World Meteorological Organization (WMO) guidelines
Wireless Features
- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors or 336 data channels per HOBO RX station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by rechargeable AA batteries and built-in solar panel
Spesifikasi
| Kategori | Spesifikasi |
|---|---|
| Measurement Range | 0 to 10.2 cm (0 to 4 in.) per hour, maksimum 4,000 tips per logging interval |
| Accuracy | ±4.0%, ±1 count (0.2–50.0 mm / 0.01–2.0 in./hr); ±5.0%, ±1 count (50.0–100.0 mm / 2.0–4.0 in./hr) |
| Resolution | 0.01 in. |
| Operating Temperature Range | -25° to 60°C (-13° to 140°F) dengan baterai rechargeable-40° to 70°C (-40° to 158°F) dengan baterai lithium |
| Radio Power | 12.6 mW (+11 dBm), non-adjustable |
| Transmission Range | 457.2 m (1,500 ft) line-of-sight pada 1.8 m (6 ft) tinggi609.6 m (2,000 ft) line-of-sight pada 3 m (10 ft) tinggi |
| Wireless Data Standard | IEEE 802.15.4 |
| Radio Operating Frequencies | RXW-RGF-900: 904–924 MHzRXW-RGF-868: 866.5 MHzRXW-RGF-922: 916–924 MHzRXW-RGF-921: 921 MHz |
| Modulation Employed | OQPSK (Offset Quadrature Phase Shift Keying) |
| Data Rate | Hingga 250 kbps (non-adjustable) |
| Duty Cycle | <1% |
| Maximum Number of Motes | Hingga 50 wireless sensors atau 336 data channels per HOBO RX station |
| Logging Rate | 1 menit hingga 18 jam |
| Number of Data Channels | 2 |
| Battery Type / Power Source | 2 x AA 1.2V NiMH rechargeable (solar panel built-in) atau 2 x AA 1.5V lithium untuk operasi -40° to 70°C |
| Battery Life | NiMH: 3–5 tahun (dalam -20° hingga 40°C dan terpapar sinar matahari)Lithium: 1 tahun penggunaan normal |
| Memory | 16 MB |
| Dimensions | Sensor: Ø16.5 cm x 24 cm tinggi (Ø6.5 in. x 9.5 in.); Area koleksi: 214 cm² (33.2 in²)Kabel: 2 m (6.6 ft)Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 in.) |
| Weight | Sensor dan kabel: 1.2 kg (2.7 lbs)Mote: 223 g (7.87 oz) |
| Materials | Sensor: UV-stabilized ABS housing, mekanisme tipping spoon dengan reed switch magnetik dan poros logamMote: PCPBT, segel karet silikon |
| Environmental Rating | Sensor: WeatherproofMote: IP67, NEMA 6 |
