RK900-01 Automatic Weather Station Meteorological Monitoring Station

Jika anda tertarik untuk membeli alat RK900-01 Automatic Weather Station Meteorological Monitoring Station yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :

PT. Samudra Teknik Solusindo

Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)

Kategori: Weather Station Brand: RIKA

Deskripsi

RK900-01 Automatic Weather Station Meteorological Monitoring Station adalah alat otomatis yang digunakan untuk mengukur berbagai parameter cuaca seperti suhu udara, kelembaban relatif, tekanan atmosfer, kecepatan dan arah angin, radiasi matahari, intensitas cahaya, curah hujan, serta suhu dan kelembaban tanah.

Stasiun cuaca ini terdiri dari berbagai jenis sensor, layar LCD, pengumpul data meteorologi, rangka penopang, dan komponen lainnya.

RK900-01 banyak digunakan dalam bidang meteorologi, hidrologi, pertanian, kehutanan, penelitian ilmiah, serta berbagai aplikasi pemantauan lingkungan lainnya.

Spesifikasi

Parts	Details	Note
Data logger	Meteorological data collection, display, storage and communications
Sensors & cable	Wind speed sensor, wind direction sensor, atmospheric temperature, atmospheric humidity, atmospheric pressure, rainfall, solar radiation, soil temperature, soil moisture,etc. (Optional according to user’s requirements)
Meteorological monitoring software	Use to real-time display, analysis and storage data on the PC	Attached
Multi-plate radiation shield	Used to install the atmospheric temperature, atmospheric humidity and atmospheric pressure sensors
Tripod & accessories	Height: 2.5m typ.,304SS or Height: 10m(4m+3m+3m) steel with coating is optional other height is optional
Protective box	Used to install data logger,solar charge controller and battery, stainless steel or steel with coating
110VAC/220VAC adapter	Optional when using AC power supply
RS485 cable	2m
RS485 converter	Signal Conversion for RS485
U disk	Used for data storage	optional
GPRS module	Used for wireless data transmission, need to match with the local mobile communication network	optional
WIFI module	Used for wireless data transmission,need for wireless networking	optional
Ethernet module	Used for wireless data transmission,need for cable network	optional
LED screen	Size and display content can be customized	optional
Solar power supply system	Include photovoltaic panels(30W), solar charge controller, 25AH battery(Can’t be transported by air. Suggest users to bring their own)	optional
Lightning protection device	Contain the lightning rod, connecting wires and grounding angle steel	optional
Windbreak wire	Used for fixing 10m support rod
Base fixed steel cage	Used for fixing 10m support rod
