Temperature/Relative Humidity (2m cable) Smart Sensor S-THC-M002
Jika anda tertarik untuk membeli alat Temperature/Relative Humidity (2m cable) Smart Sensor S-THC-M002 yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :
PT. Samudra Teknik Solusindo
Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Deskripsi
Temperature/Relative Humidity (2m cable) Smart Sensor S-THC-M002 dirancang untuk bekerja dengan semua pencatat data HOBO yang menerima Smart Sensor. Semua parameter sensor disimpan di dalam Smart Sensor, yang secara otomatis mengkomunikasikan informasi data konfigurasi ke pencatat data tanpa pemrograman, kalibrasi, atau pengaturan pengguna yang ekstensif.
Temperature/Relative Humidity (2m cable) Smart Sensor S-THC-M002 Juga tersedia dalam model nirkabel untuk digunakan dengan Sistem Pemantauan Lapangan HOBOnet.
Features
- Smart Sensor
- Works with all loggers that accept Smart Sensor inputs
- Automatically communicates configuration data to the logger
Spesifikasi
| Category | Specification |
|---|---|
| Measurement Range | Temp: -40°C to 75°C (-40°F to 167°F) RH: 0–100%* RH at -40° to 75°C (-40° to 167°F); exposure below -20°C or above 95% RH may increase sensor error by ~1% |
| Accuracy | Temp: ±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F); ±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F); ±0.25°C from 70° to 75°C (±0.45°F from 158° to 167°F) RH: ±2.5% from 10% to 90% RH (typical), max ±3.5% including hysteresis at 25°C (77°F); ±5% typical below 10% or above 90% |
| Resolution | Temp: 0.02°C RH: 0.01% RH |
| Bits per Sample | Temp: 16 RH: 16 |
| Drift | Temp: < 0.01°C (0.18°F) per year RH: < 1% per year typical |
| Response Time (90%) | Temp: 3 min 45 sec (w/o shield) or 6 min 30 sec (with RS3-B shield) in 1 m/s air RH: 15 sec (w/o shield) or 30 sec (with RS3-B shield) |
| Sensor Operating Temp | -40°C to 75°C (-40°F to 167°F) |
| Environmental Rating | Weatherproof; 0 to 100% RH, intermittent condensing. Best used with radiation shield for sun and splash protection |
| Housing | PVC cable jacket; ASA styrene polymer RH sensor cap; hydrophobic polyethersulfone membrane |
| Sensor Dimensions | 45.97 x 11.43 x 10.16 mm (1.81 x 0.45 x 0.40 in.) |
| Weight | 110 g (3.88 oz) |
| Number of Data Channels | 2 |
| Measurement Averaging | No |
| Cable Length Available | 2.5 m (8.2 ft) |
| Smart Sensor Network Cable | 0.5 m (1.6 ft) |
| Notices | * Maximum 100% RH readings only logged with RX3000 stations. U30 and H21 max is ~99.99%. ** One HOBO station supports 15 data channels and up to 100 m (328 ft) of sensor cable |
