Ultrasonic Wind Speed & Direction Smart Sensor S-WCG-M003

Jika anda tertarik untuk membeli alat Ultrasonic Wind Speed & Direction Smart Sensor S-WCG-M003 yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :

PT. Samudra Teknik Solusindo

Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)

Kategori: Data Logger Brand: HOBO

Deskripsi

Ringkas dan kokoh tanpa bagian yang bergerak, sensor ultrasonik ini mampu mengukur kecepatan angin yang sangat rendah, hingga 0,4 m/detik (dibandingkan dengan 1,0 m/detik untuk sensor mekanis kami). Seperti halnya semua Sensor Cerdas Onset, sensor ini plug-and-play dengan stasiun HOBO (RX3000, RX2100, USB Micro Station, H22, dan U30-NRC). Karena secara otomatis dikenali oleh stasiun HOBO, maka tidak diperlukan pemrograman, sehingga penerapannya cepat dan mudah. Sensor ini ditenagai oleh panel surya internal miliknya sendiri.

Tertarik dengan sensor nirkabel? Sensor Kecepatan & Arah Angin nirkabel tersedia untuk digunakan dengan Sistem Pemantauan Lapangan HOBOnet.

Features

Compact and rugged with no moving parts
Plug-and-play with HOBO stations
No starting threshold – suitable for low wind speeds
No wind direction dead band – accurate wind data in all directions
Powered by its own built-in solar panel
Affordably priced

Spesifikasi

	Wind Speed/Gust	Wind Direction
Measurement Range	0 to 41.16 m/s (0 to 92.07 mph)	0 to 359 degrees
Accuracy	±0.8 m/s (1.79 mph) or ±4% of reading, whichever is greater	0.2 to 3 m/s (0.44–6.7 mph): ±4 degrees >3 m/s (6.7 mph): ±2 degrees
Resolution	0.4 m/s (0.89 mph)	1 degrees (0 to 359 degrees)
Measurement Definition	Wind speed readings are taken every three seconds for the duration of the logging interval Wind speed: Average speed for the entire logging interval Gust speed: The highest three-second wind recorded during the logging interval See Measurement Operation.	Unit vector averaging used; vector components for each wind measurement are calculated every three seconds for duration of logging interval (see Measurement Operation)
Operating Temperature Range Without Icing	-15°C to 55°C (5°F to 131°F)
Environmental Rating	Weatherproof
Housing	Polyacetal
Dimensions	Sensor length: 380 mm (14.96 inches) Sensor head diameter: 60 mm (2.36 inches) Sensor rod diameter: 16 mm (0.63 inches)
Weight	200 g (7 oz)
Power Supply	Photovoltaic panel, LIFEP04 3.2 V -600 mAh battery
Bits per Sample	8 for each channel, 24 total
Number of Data Channels*	3
Measurement Averaging Option	Automatic averaging (see Measurement Operation)
Cable Length Available	3 m (9.8 ft)
Length of Smart Sensor Network Cable*	0.5 m (1.6 ft)
	The CE Marking identifies this product as complying with all relevant directives in the European Union (EU).

* A single HOBO station can accommodate 15 data channels and up to 100 m (328 ft) of smart sensor cable (the digital communications portion of the sensor cables).
