HOBO MX800 Series Water Data Loggers MX801 – MX802
Jika anda tertarik untuk membeli alat HOBO MX800 Series Water Data Loggers MX801 – MX802 yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :
PT. Samudra Teknik Solusindo
Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Deskripsi
Pencatat data nirkabel multiparameter HOBO MX800 Series Water Data Loggers bekerja dengan sensor yang dapat dipertukarkan untuk memberikan solusi yang sangat mudah dikonfigurasi untuk memantau konduktivitas / salinitas air, suhu, kedalaman, dan oksigen terlarut. Tersedia dalam model yang mudah digunakan dan dapat direndam sepenuhnya (MX801) dan model pembacaan langsung (MX802) untuk memudahkan pembongkaran data yang tidak perlu mengeluarkan sensor dari dalam air.
Features
- Compatible with interchangeable Conductivity, CTD (conductivity/temperature/depth), and DO sensors (sold separately) – swap out sensors for different applications
- Bluetooth, for easy logger configuration and data offload
- Easy to deploy, fully submersible (MX801)
- Direct read for convenient data offload (MX802)
- Logger diameter is less than 2 inches
- Faster data offload via Bluetooth 5.0
- Water detect feature indicates when logger was out of the water (MX801)
- Barometric pressure sensor included (MX802)
- Connect two sensors to one logger to get measurements like salinity adjusted DO directly, with no need for post-processing
- Guided calibration ensures accurate data
- User-replaceable batteries
Spesifikasi
| Specification | Description |
|---|---|
| Operating Range | -40° to 50°C (-40° to 122°F), cannot be frozen in ice |
| Radio Power | 1 mW (0 dBm) |
| Transmission Range | Approximately 30.5 m (100 ft) line-of-sight |
| Wireless Data Standard | Bluetooth 5 |
| Number of Sensors Supported | 2 |
| Maximum Cable Length | 120 m (400 ft) |
| Logging Rate | 5 seconds to 18 hours |
| Logging Modes | Fixed interval (normal or statistics), burst, or multiple intervals with up to 8 user-defined logging intervals and durations, with pause and repeat options |
| Start Modes | Immediate, next interval, or date & time |
| Stop Modes | Memory full, never stop (overwrite oldest data), date & time, or after a set logging period |
| Water Detect | Events logged when submerged or removed from water (MX801 only) |
| Time Accuracy | ±1 minute per month from 0° to 50°C (32° to 122°F) |
| Battery | Four AA, 1.5 V lithium batteries, user replaceable |
| Battery Life | With W-CTD or W-CT sensors: 2 years (typical @ 1-minute interval)With W-DO sensor: 1 year (typical @ 5-minute interval)Note: Faster logging, burst mode, frequent connections reduce battery life |
| Memory | 730,000 measurements, divided between channels (4 MB memory) |
| Data Download Time | Full memory: ~3.5 minutes (Bluetooth 5+)120,000 measurements: ~1 minute |
| Barometric Pressure (MX802 only) | Measurement & Calibrated Range: 66 to 107 kPa (9.6 to 15.5 psia), -20° to 50°C (-4° to 122°F)Accuracy: ±0.2 kPa (typical), ±0.5 kPa (max)Resolution: <0.01 kPa (0.0015 psi)Response Time: <1 second (90%)Water Level Accuracy Contribution: ±0.075% FS, 0.3 cm (typical); ±0.15% FS, 0.6 cm (max) |
| Dimensions | Logger Diameter: 4.14 cm (1.63 in)Length without sensor: 20 cm (8 in)With W-CTD: 36 cm (14 in)With W-CT: 33 cm (13 in)Mounting loop: 12.7 x 22.6 mm (0.5 x 0.89 in) |
| Weight | MX801: 224 g (7.90 oz)MX802: 226 g (7.97 oz) |
| Wetted Materials | Logger: PVC housing, polyester label, PET connector & handle, EPDM & Buna-N O-rings, passivated 316 SS hardware (saltwater rated); MX802 includes ePTFE ventCollar: HDPE, titanium screwsNote: avoid metal-to-metal contact with logger |
| Depth/Environmental Rating | MX801: IP68, waterproof to 100 m (with sensors attached)MX802: IP67 / NEMA 6, weatherproof (with cable or plug); not waterproof |
