HOBO Temp/RH/Light/Ext-Analog Data Logger MX1104
Jika anda tertarik untuk membeli alat HOBO Temp/RH/Light/Ext-Analog Data Logger MX1104 yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :
PT. Samudra Teknik Solusindo
Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)
Deskripsi
HOBO Temp/RH/Light/Ext-Analog Data Logger MX1104 mengukur dan mengirim data suhu, kelembapan relatif, dan intensitas cahaya secara nirkabel. Perangkat ini juga menyediakan input analog eksternal untuk menyambungkan berbagai sensor tambahan sesuai kebutuhan pemantauan.
Pencatat data nirkabel ini mandiri, berkemampuan Bluetooth, dan mudah diakses. Anda dapat menggunakan aplikasi HOBOconnect gratis dari Onset melalui perangkat seluler atau komputer Windows untuk membaca data dalam jarak 100 kaki. Anda dapat mengatur pencatat, membaca data, menampilkan grafik, memeriksa status, mengatur alarm, dan membagikan file data tanpa peralatan tambahan.
Beli Paket Data MX untuk mengakses lebih banyak data dari mana saja melalui platform LI-COR Cloud (sebelumnya HOBOlink). Anda juga dapat menggunakan stasiun MX Gateway yang otomatis mengirimkan data ke LI-COR Cloud melalui koneksi Bluetooth.
Features
- Bluetooth communication for wireless data offload
- 16-bit resolution for highly-accurate measurements
- Stores 1.9 million measurements for longer deployments between offloads
- New Self-Describing sensors with automatic configuration for fast deployment
- Compatible with existing sensors for a wide range of indoor monitoring
- Audible and visual LCD-screen alarms notify you if sensor becomes unplugged or a reading exceeds set thresholds
Spesifikasi
Temperature Sensor (MX1104)
| Parameter | Specification |
|---|---|
| Range | -20° to 70°C -4° to 158°F |
| Accuracy | ±0.20°C from 0° to 50°C ±0.36°F from 32° to 122°F |
| Resolution | 0.002°C at 25°C 0.004°F at 77°F |
| Drift | <0.1°C (0.18°F) per year |
| Response Time | 11 minutes in air moving 1 m/s (2.2 mph) |
Relative Humidity (RH) Sensor (MX1104)*
Exposure above 95% RH may temporarily increase max error by an additional 1%
| Parameter | Specification |
|---|---|
| Range | 0% to 100% RH at -20° to 70°C (-4° to 158°F) |
| Accuracy | ±2.5% from 10% to 90% RH (typical), max ±3.5% incl. hysteresis at 25°C (77°F) ±5% typical below 10% and above 90% RH |
| Resolution | 0.01% RH |
| Drift | <1% RH per year (typical) |
| Response Time | 30 seconds to 90% in airflow of 1 m/s (2.2 mph) |
Light Sensor (MX1104)
| Parameter | Specification |
|---|---|
| Range | 0 to 167,731 lux 15,582 lum/ft² |
| Accuracy | ±10% typical for direct sunlight (see Light Measurement p. 4) |
Logger Specifications (MX1104)
| Parameter | Specification |
|---|---|
| Operating Range | -20° to 70°C -4° to 158°F |
| Radio Power | 1 mW 0 dBm |
| Transmission Range | Approximately 30.5 m (100 ft) line-of-sight |
| Wireless Data Standard | Bluetooth Low Energy (Bluetooth Smart) |
| Logging Rate | 1 second to 18 hours |
| Logging Modes | Fixed interval (normal, statistics) or burst |
| Memory Modes | Wrap when full or stop when full |
| Start Modes | Immediate, push button, date & time, or next interval |
| Stop Modes | When memory full, push button, date & time, or after a set logging period |
| Restart Mode | Push button |
| Time Accuracy | ±1 minute per month at 25°C (77°F) |
| Battery Type | Two AAA 1.5 V alkaline batteries, user-replaceable |
| Battery Life | 1 year (typical, with 1-minute logging & Bluetooth Always On) 2 years (with Bluetooth Always Off) |
| Battery life affected by logging rate, burst mode, frequent downloads, app connection, etc. | |
| Memory | 4 MB (up to 1.9 million measurements) |
| Full Memory Download Time | Approximately 4 to 15 minutes (depends on device & distance) |
| LCD Display | Visible from 0° to 50°C (32° to 122°F); may react slowly or go blank outside this range |
| Size | 11.28 x 5.41 x 2.92 cm 4.44 x 2.13 x 1.15 in. |
| Weight | 123 g 4.34 oz |
| Environmental Rating | IP54 |
