HOBOnet Wireless Temperature Sensor RXW-TMB-x-xxx

Jika anda tertarik untuk membeli alat HOBOnet Wireless Temperature Sensor RXW-TMB-x-xxx yang disediakan oleh PT Samudra Teknik Solusindo, silahkan hubungi kami melalui :

PT. Samudra Teknik Solusindo

Alamat: Jl. Pd. Kelapa Raya No.8D Blok E10, RT.9/RW.11, Pondok Kelapa, Durensawit, East Jakarta City, Jakarta 13450
Whatsapp : +62 851‑9090‑8341 (Dani)
Email : sales.stsolusindo@gmail.com
Telp : +62 851‑9090‑8341 (Dani)

Kategori: Data Logger Brand: HOBO

Deskripsi

Solusi yang hemat biaya dan dapat diskalakan untuk pemantauan suhu udara berbasis web. HOBOnet Wireless Temperature Sensor mengkomunikasikan data secara langsung ke Stasiun HOBO RX atau meneruskan data melalui sensor nirkabel lainnya kembali ke stasiun pusat. Sensor ini telah dikonfigurasikan sebelumnya dan siap digunakan, dan data diakses melalui HOBOlink, platform perangkat lunak cloud Onset yang inovatif.

Features

Sensor Features

Measurement range of -40° to 100°C (-40° to 212°F)
High accuracy: ± 0.2°C ( ± 0.36°F)
Stainless-steel sensor tip

Wireless Features

900 MHz wireless mesh self-healing technology
450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
Up to 50 wireless sensors or 336 data channels per HOBO RX station
Simple button-push to join the HOBOnet wireless network
Onboard memory to ensure no data loss
Powered by 2 user-replaceable lithium AA batteries

Spesifikasi

Category	Parameter	Specification
Sensor	Measurement Range	-40° to 100°C (-40° to 212°F)
	Accuracy	±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F)
		±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F)
		±0.25°C from 70° to 100°C (±0.45°F from 158° to 212°F)
	Resolution	0.02°C (0.036°F)
	Drift	<0.01°C (0.018°F) per year
	Response Time (90%)	2 minutes, 30 seconds in air at 1 m/sec
Wireless Mote	Operating Temperature Range	-40° to 70°C (-40° to 158°F)
	Radio Power	12.6 mW (+11 dBm), non-adjustable
	Transmission Range	457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) height
		609.6 m (2,000 ft) line of sight at 3 m (10 ft) height
	Wireless Data Standard	IEEE 802.15.4
	Radio Operating Frequencies	RXW-TMB-x-900: 904–924 MHzRXW-TMB-x-868: 866.5 MHzRXW-TMB-x-921: 921 MHzRXW-TMB-x-922: 916–924 MHz
	Modulation Employed	OQPSK (Offset Quadrature Phase Shift Keying)
	Data Rate	Up to 250 kbps, non-adjustable
	Duty Cycle	<1%
	Max Number of Motes	Up to 50 wireless sensors or 336 data channels per HOBO RX station
	Logging Rate	1 minute to 18 hours
	Number of Data Channels	2
	Battery Type	Two AA 1.5 V lithium batteries
	Battery Life	1 year (typical use)
	Memory	16 MB
Physical Dimensions	Sensor Size	5.3 × 33 mm (0.2 × 1.3 in)
	Cable Length	0.3 m (1 ft) for RXW-TMB-1-xxx1.8 m (6 ft) for RXW-TMB-6-xxx
	Mote Size	16.2 × 8.59 × 4.14 cm (6.38 × 3.38 × 1.63 in)
	Weight	Sensor + cable: 7.6 g (0.27 oz) [1 ft], 35.2 g (1.24 oz) [6 ft]Mote: 223 g (7.87 oz)
	Materials	Sensor: Stainless steel waterproof tipMote: PCPBT, silicone rubber seal
Environmental Rating	Sensor & Cable	Immersion in water up to 50°C (122°F) for 1 year
	Mote	IP67, NEMA 6
